Product features

for perfect coffee indulgence

Perfect milk foam

Perfect milk foam

Thermoplan has been a pioneer and innovator in the automatic production of the finest and most stable milk foam since the early 1990s. Heat up milk and gently froth, create even cold milk foam with a unique consistency: All this can be accomplished simply and at the touch of a button thanks to our unique milk foam technology.

Form & Function BW4 compact

Form & Function

The Black&White4 compact is the trend setter among the fully automatic coffee machines. Its clear design and high quality materials are impressive. This coffee machine is designed for heavy duty use in professional restaurants and cafés. Well thought-out design details, such as the robust display made of tempered glass, makes it easier to operate and optimally supports the machine’s functions.

Intuitive operation

Intuitive operation

The Black&White4 compact makes life easy for its users. The easy-to-understand user interface of the professional coffee machine enables intuitive and user-friendly handling. Status reports and recorded data can be read out via an interface or data carrier.

Self Serve options
Perfected modularity

Perfected modularity

The Black&White4 compact impresses with a modular system in its fourth generation. All basic functions of the fully automatic coffee machine are set up into only two machine modules: mechanical and hydraulic. Maintenance and service work is performed exclusively on these components, the chassis remains untouched. As a result, each unit is back in use in no time.

Easy Cleaning and Care
Easy Cleaning and Care

Easy Cleaning and Care

Hygiene, safety and simplicity are the most important prerequisites for the cleaning and care of fully automatic coffee machines. The hygienic quality of Black&White4 compact is HACCP, HCV and NSF-certified. Thanks to the well-thought out technology, the fully automatic coffee machine is extraordinarily simple and quick to clean: a major advantage in the hectic everyday restaurant business.

Product Environmental Report

Thermoplan operates fully transparent when it comes to sustainability. The Product Environmental Report provides insight into the energy efficiency, footprint and recycling of the fully automatic coffee machines.

To the Product Environmental Report

Options

for the perfect coffee indulgence

Refrigerator

Integrated cooling unit for 4 liters of chilled milk

Milk and milk foam unit with Black&White4 compact
Black&White4 compact

Flavor unit

Compartment for up to 4 syrup flavors

Flavour drinks with Black&White4 compact
Flavor unit

Powder unit

Chocolate powder for vending machines

Powder unit
Powder unit

Accessories

Cupheater CH

Storage from 100 to 150 cups

Data sheet Tender specifications

Payment housing

Design-compliant side housing for your cashless payment system

Data sheet

Freely selectable configuration

Number of possible combinations

Legend

C

Coffee (coffee unit)

T

Tea (hot water unit)

M

Milk (milk and milk foam unit)

RS

Refrigerator small (refrigeration unit for 4 liters of milk)

F

Flavor unit (compartment for up to 4 syrup flavors)

P

Powder unit (chocolate powder for vending machines)

CH

Cup heater

Black&White4 compact CTM

Get maximum coffee and milk beverage quality even if you’re tight on space. Only 228 mm wide the Black&White4 compact in its basic configuration CTM (coffee-tee-milk) is a true space saver.

  • Capacity per hour
  • 180 espressos
  • 120 coffees
  • 100 cappuccinos
  • 90 teas
  • Amount depends on cup size and machine setting
  • Bean hopper 1 kg
  • Electrical connection
  • 220-240 VAC / 50-60 Hz
  • 2700-3100 W / 12-13 A
  • Dimensions
  • 228 x 600 x 646 mm (W/D/H)
  • Weight
  • 40 kg

Black&White4 compact CTM RS

The professional machine is only slightly wider with an integrated refrigerator RS. The Black&White4 in the configuration CTM RS brings together what belongs together and combines excellent coffee and milk foam know-how.

  • Capacity per hour
  • 180 espressos
  • 120 coffees
  • 100 cappuccinos
  • 90 teas
  • Amount depends on cup size and machine setting
  • Bean hopper 1 kg
  • RS refrigerator 4 liters
  • Electrical connection
  • 220-240 VAC / 50-60 Hz
  • 2700-3150 W / 12-13 A
  • Dimensions
  • 398 x 600 x 646 mm (W/D/H) (with RS)
  • Weight
  • 56 kg (with RS)

Black&White4 compact CTM F / CTM F RS

Never has there been a flavored latte macchiato prepared more quickly or simply. With the Black&White4 compact CTM F/CTM F RS, excellent coffee and milk specialties with extraordinary flavors can be created at the touch of a button.

  • Capacity per hour
  • 180 espressos
  • 120 coffees
  • 100 cappuccinos
  • 90 teas
  • Amount depends on cup size and machine setting
  • Bean hopper 1 kg
  • RS refrigerator 4 liters
  • Number of syrup flavors 1 – 4 flavors
  • Electrical connection
  • 220-240 VAC / 50–60 Hz
  • 2700-3150 W / 12-13 A
  • Dimensions
  • 398 x 600 x 646 mm (W/D/H)
  • 568 x 600 x 646 mm (W/D/H) (with RS)
  • Weight
  • 50 kg
  • 62 kg (with RS)

Black&White4 compact CTM P / CTM P RS

An absolute must for chocolate aficionados! The Black&White4 compact CTM P/CTM P RS creates hot chocolate with a simple touch of a button and tops it off with creamy, smooth milk foam. As expected coffee enthusiasts are also provided maximum beverage quality with this professional machine.

  • Capacity per hour
  • 180 espressos
  • 120 coffees
  • 100 cappuccinos
  • 90 teas
  • 80 chocolate beverages
  • Amount depends on cup size and machine setting
  • Bean hopper 1 kg
  • RS refrigerator 4 liters
  • Powder container 2 kg
  • Electrical connection
  • 220-240 VAC / 50-60 Hz
  • 2700-3150 W / 12-13 A
  • Dimensions
  • 320 x 600 x 646 mm (W/D/H)
  • 490 x 600 x 646 mm (W/D/H) (with RS)
  • Weight
  • 52 kg
  • 68 kg (with RS)

Black&White4 compact CTM PF / CTM PF RS

Whether in the office, the hotel lobby, in the bakery or at the kiosk: The Black&White4 compact CTM PF/CTM PF RS meets every demand. With the powder and flavor units for chocolate powder and syrup flavors coffee and milk specialties obtain an individual flavor.

  • Capacity per hour
  • 180 espressos
  • 120 coffees
  • 100 cappuccinos
  • 90 teas
  • 80 chocolate beverages
  • Amount depends on cup size and machine setting
  • Bean hopper 1 kg
  • RS refrigerator 4 liters
  • Powder container 2 kg
  • Number of syrup flavors 1 – 4 flavors
  • Electrical connection
  • 220-240 VAC / 50-60 Hz
  • 2700-3150 W / 12-13 A
  • Dimensions
  • 490 x 600 x 646 mm (W/D/H)
  • 660 x 600 x 646 mm (W/D/H) (with RS)
  • Weight
  • 62 kg
  • 78 kg (with RS)

Black&White4 compact CTM & CTM RS

The Black&White4 compact TwinTower consists of a CTM (coffee-tea-milk) configuration and a CTM RS (coffee-tea-milk) configuration with a 4 liter refrigerator. The refrigerator can easily be extended with an under-counter refrigerator option.

  • Capacity per hour
  • 360 espressos
  • 240 coffees
  • 180 teas
  • 200 cappuccinos
  • Amount depends on cup size and machine setting
  • Bean hopper 4x 1 kg
  • Refrigerator 4 liters
  • Electrical connection
  • 2x 220-240 VAC / 50-60 Hz
  • 2700-3150 W / 12-13 A
  • Dimensions
  • 626 x 600 x 646 mm (W/D/H)
  • Weight
  • 96 kg
